Misha™ is an innovative Eurorack instrument/sequencer that utilises a unique, interval-based approach to playing and creating melodies. It’s designed to be played like a keyboard instrument, and yet it makes music in a way unlike any instrument before it. In addition to playing it live, you can also record sequences that can be modified in a multitude ofways, allowing for new paths of spontaneous creativity.

Features:

• An innovative 28hp Eurorack instrument/sequencer that utilises a unique, interval-based approach to playing and creating melodies
• Make sound three ways via MIDI, control voltage (with three independent gate/cv pairs), or outputting waveforms via the audio jack
• External control templates for MIDI and QWERTY keyboards
• 100 factory scales and additional slots for up to 100 user/custom scales (Scala support)
• Tone row-based sequencer inspired by the classic compositional technique used in serial music
• Comprehensive control of sequence playback to easily manipulate and expand upon your musical ideas
• Create rhythmic variations using clock division
• Four user-assignable buttons
• 18 user presets
• CV inputs for external trigger/control sources
• Clock input for syncing to external sources. User-configurable PPQ settings
• Audio output for internal oscillator
• Polyphony via 3 CV outputs or MIDI
• Micro-USB for easy firmware updates using Eventide Device Manager
• Micro-SD card for saving/loading scales and settings

Specifications:

• Eurorack: 28hp
• Stereo Audio Out: 2 channels/stereo, DC coupled
• Line Output: Transformer-coupled, balanced XLR and TRS 1/4
• Side-chain Input: Active balanced XLR and TRS 1/4
• Side-chain Output: Active balanced XLR and TRS 1/4
• Link Input: Control voltage, TS 1/4
• Link Output: Control voltage, TS 1/4
• Output CV: -5V to +5V, 0 to 5V, 0V to +10V (configurable)
• Input CV: -5V to +5V, 0 to 5V, 0V to +10V (configurable)
• MIDI: TRS Type A
• Power: +12VDC/105mA, -12VDC/5mA
• Dimensions: 28HP Eurorack, 3⁄4”(~19mm) deep
